Name: JL-224 UK Gauge Polygonal Shell
Brand: Shanghai Long-Join Intelligent Technology Inc.

JL-224 UK Gauge Polygonal Shell Overview:

The JL-224B photocontrol is designed for the automatic regulation of street, garden, corridor, and entrance lighting, based on the surrounding environmental light levels. It features electronic circuitry with a phototransistor sensor and includes a surge arrester (MOV) for protection. Notably, the JL-224B model is equipped with an omnidirectional top-facing sensor, tailored for customer applications in accordance with BS5972 standards. Additionally, a built-in time delay function of 5-30 seconds helps prevent unnecessary activation caused by vehicle headlights or nighttime lightning. This product is fitted with twist-lock terminals that satisfy the criteria of BS5972, and the series adheres to the CE and RoHS directives.

JL-224 UK Gauge Polygonal Shell Specifications

Model No.	JL-224B	JL-224C
Rated Voltage	220~240VAC	120~277VC
Applicable Voltage Range	—	105~305VAC
Rated Frequency	50/60Hz
Rated Loading	1000W Tungsten, 1000VA Ballast
Power Consumption	8W@240VAC		3W@120VAC
Operate Levels	On＜20Lx，off＞80Lx
Ambient Temperature	-40℃ ~ +70℃
Related Humidity	96%
Fail Mode	Fail-Off
Shell material	PC
IP level	IP54
