Name: JL-106 Large Size Direct
Brand: Shanghai Long-Join Intelligent Technology Inc.

JL-106 Large Size Overview：

The JL-106 photocontrol unit is suitable for automatically regulating the lighting in passageways and entrance areas, responding to the outdoor light conditions. Engineered with an electrical heating element, it incorporates a 30-second plus time delay feature to prevent unnecessary toggling of lights caused by momentary bright lights or nighttime lightning. The unit includes a temperature compensation system to ensure reliable operation across different temperature ranges. The swivel model of the JL-106 allows for easy adjustment of the direction after it has been installed.

JL-106 Large Size Direct Specifications

Model No.	JL-106A（*V）	JL-106B（*V）	JL-106C（*V）	JL-106D（*V）
Rated Voltage	120VAC	220~240VAC	208~277VAC	277VAC
Applicable Voltage Range	—		200~305VAC	—
Rated Frequency	50/60Hz
Rated Loading	2000W Tungsten, 2000VA Ballast
Power Consumption	1.5W Max.
Operate Levels	10~20Lx Turn-On / 30~60Lx Turn-Off
Ambient Temperature	-40℃ ~ +70℃
Related Humidity	96%
Fail Mode	Fail-On
Lead Wire	AWG#16, AWM3321 4" min
Certifications
