Name: JL-106V Large Size
Brand: Shanghai Long-Join Intelligent Technology Inc.

JL-106V Large Size Overview:

The JL-106 photocontrol is designed to autonomously manage lighting in corridors and entryways, syncing with the environmental light levels. Constructed with an electrical heating element, it features an extended time delay of more than 30 seconds to prevent extraneous triggering by headlights or nocturnal lightning strikes. An integrated temperature compensation system ensures stable operation across varying temperature conditions. Additionally, the unit comes in a swivel configuration, facilitating easy directional alignment once mounted.

JL-106V Large Size Specifications

Model No.	JL-106A（*V）	JL-106B（*V）	JL-106C（*V）	JL-106D（*V）
Rated Voltage	120VAC	220~240VAC	208~277VAC	277VAC
Applicable Voltage Range	—		200~305VAC	—
Rated Frequency	50/60Hz
Rated Loading	2000W Tungsten, 2000VA Ballast
Power Consumption	1.5W Max.
Operate Levels	10~20Lx Turn-On / 30~60Lx Turn-Off
Ambient Temperature	-40℃ ~ +70℃
Related Humidity	96%
Fail Mode	Fail-On
Lead Wire	AWG#16, AWM3321 4" min
Certifications
