Name: JL-214 UK Version Steeple Top Cover
Brand: Shanghai Long-Join Intelligent Technology Inc.

JL-214 UK Version Steeple Top Cover Overview:

The PECU JL-214B is suited for the automatic regulation of street, garden, corridor, and entrance lighting, aligning with the surrounding natural light levels. This device is crafted with electronic circuits that incorporate a phototransistor sensor and is equipped with a surge arrester (MOV) for protection. Notably, the JL-214B model features a top-facing sensor, which is customizable for applications as per BS5972 standards. Additionally, it includes a pre-set time delay of 5-30 seconds to prevent unnecessary activation from headlights or nocturnal lightning. The product is fitted with twist-lock terminals that satisfy the criteria of BS5972. This series adheres to the CE (UKCA) and RoHS directives.

JL-214 UK Version Steeple Top Cover Specifications

Model No.	JL-214B
Rated Voltage	220~240VAC
Rated Frequency	50/60Hz
Rated Loading	1000W Tungsten, 1800VA Ballast
Power Consumption	8W@240VAC
Operate Levels	On
Ambient Temperature	-40℃~+70℃
Related Humidity	96%
Fail Mode	Fail-Off
Shell material	PC
IP level	IP54
Certifications
