Name: JL-118 With Light Adjustment Bar
Brand: Shanghai Long-Join Intelligent Technology Inc.

JL-118 With Light Adjustment Bar Overview:

The JL-118 series photoelectric sensor is designed for the automatic management of lighting in corridors and entryways, responding to the level of environmental light. Constructed with an electrical heating element, it incorporates a delay of more than 30 seconds to prevent unnecessary activation due to vehicle headlights or nighttime lightning. A built-in temperature compensation system ensures reliable operation across various temperature extremes. The unit’s swivel model simplifies post-installation orientation adjustments.

JL-118 With Light Adjustment Bar Specifications

Model No.	JL-118A（V）	JL-118B（V）	JL-118C（V）	JL-118D（V）
Rated Voltage	120VAC	220~240VAC	208~277VAC	277VAC
Applicable Voltage Range	—		200~305VAC	—
Rated Frequency	50/60Hz
Rated Loading	1800W Tungsten, 1100VA Ballast
Power Consumption	1.5W Max.
Operate Levels	10~20Lx Turn-On / 30~60Lx Turn-Off
Ambient Temperature	-40℃ ~ +70℃
Related Humidity	96%
Fail Mode	Fail-On
Lead Wire	AWG#16, AWM3321 4"min
Certifications
