Name: JL-116V ''V'' Version With Light Adjustment Bar
Brand: Shanghai Long-Join Intelligent Technology Inc.

JL-116V ''V'' Version With Light Adjustment Bar Overview:

The JL-116 photocontrol unit is intended for the automatic regulation of lighting in hallways and entrance areas, contingent on the surrounding light conditions. It features an electrical heating mechanism that initiates a delay of more than 30 seconds to prevent frequent toggling caused by headlights or nocturnal lightning flashes. Equipped with a temperature compensation system, it maintains uniform operation across a range of temperatures. The unit is adaptable for directional changes post-installation, with the added convenience of a swivel adapter.

JL-116V ''V'' Version With Light Adjustment Bar Specifications

Model No.	JL-116A（*V）	JL-116B（*V）	JL-116C（*V）	JL-116D（*V）
Rated Voltage	120VAC	220~240VAC	208~277VAC	277VAC
Applicable Voltage Range	—		200~305VAC	—
Rated Frequency	50/60Hz
Rated Loading	2000W Tungsten, 2000VA Ballast
Power Consumption	1.5W Max.
Operate Levels	10~20Lx Turn-On / 30~60Lx Turn-Off
Ambient Temperature	-40℃ ~ +70℃
Related Humidity	96%
Fail Mode	Fail-On
Lead Wire	AWG#16, AWM3321 4"min
Certifications
